Hyundai Tiburon (2003 year). Manual - part 206
TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body Electrical System > Fuses And Relays > Relay Box
(Passenger Compartment) > Repair procedures, TIBURON(GK) > 2003 > G 2.7 V6 DOHC > Body
Electrical System > Fuses And Relays > Relay Box (Passenger Compartment) > Repair procedures
INSPECTION
1. Check for a burnt relay with an ohmmeter.
2. If a relay burns out, there is a short or some other problem in the circuit. Carefully determine the cause and
correct it before replacing therelay.
INSPECTION OF FUSES
1. Fuse blown due to over-current.
Prior to replacing the fuse with a new one, check the circuit for a short and the related parts for abnormal
conditions. Only after the correction of a short or replacement of abnormal parts, should a fuse with the same
ampererating be installed.
2. Fuse blown due to repeated on-off current.
Normally, this type of problem occurs after a fairly long period of use, and is less frequent than #1 above. In
this case, you may simply replacewith a new fuse of the same capacity.
A blade type fuse is identified by the numbered value in amperes. If the fuse is blown, be sure to replace a
fuse with the same ampere rating. If a fuse of higher capacity than specified is used, parts may be damaged
and a danger of fire exists. To remove or insert a fuse, use the fuse pullerin the fuse box.
