Ford F150 Pickup. Instruction - part 336

Fig. 58: Disconnecting Windshield Washer Hose
Courtesy of FORD MOTOR CO.

6. Disconnect the windshield washer hose.

7. Remove the windshield washer reservoir.

8. Remove the windshield washer pump (17664) if necessary.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Wipers and Washers - F150 Pickup



Fig. 59: Identifying Windshield Washer Pump
Courtesy of FORD MOTOR CO.

Installation



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Wipers and Washers - F150 Pickup



1. To install, reverse the removal procedure.

z

Fill the windshield washer reservoir with ultra-clear windshield washer concentrate C9AZ-19550-
AC or BC or equivalent meeting Ford specification ESR-M17P5-A.

Fig. 60: Installing Windshield Washer Reservoir
Courtesy of FORD MOTOR CO.

CAUTION: Do not make electrical connection prior to filling the windshield

washer reservoir. Do not operate the windshield washer pump prior
to filling the windshield washer reservoir.

NOTE:

When the battery (10655) is disconnected and reconnected, some
abnormal drive symptoms may occur while the vehicle relearns its
adaptive strategy. The vehicle may need to be driven 16 km (10 miles) or
more to relearn the strategy.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Wipers and Washers - F150 Pickup



2003 GENERAL INFORMATION

Brake System - General Information - F150 Pickup

SPECIFICATIONS

TORQUE SPECIFICATIONS

TORQUE SPECIFICATIONS

DESCRIPTION NUMBER

DESCRIPTION AND OPERATION

BRAKE SYSTEM

Description

Nm

lb-ft

Brake master cylinder tube fitting

17.5

13

Caliper bleeder screw, rear

20

15

Description

Nm

lb-ft

Caliper bleeder screw, front

15

11

Wheel cylinder bleeder screw

15

11



2003 Ford Pickup F150

2003 GENERAL INFORMATION Brake System - General Information - F150 Pickup





2003 Ford Pickup F150

2003 GENERAL INFORMATION Brake System - General Information - F150 Pickup
