Fig. 114: Identifying Rear Door Window Regulator - Supercrew Special Tool(s)
Courtesy of FORD MOTOR CO.

Removal and Installation

1. Remove the door speaker. Refer to SPEAKERS -- DOOR MOUNTED .

2. Remove the screws and the trim panel brace.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 115: Removing Screws And Trim Panel Brace
Courtesy of FORD MOTOR CO.

3. Remove the rear door water shield.

4. Lower the window glass to access the window glass to regulator nuts.

5. Remove the window glass to regulator nuts.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 116: Identifying Regulator Nuts
Courtesy of FORD MOTOR CO.

6. Raise the window glass to the closed position.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 117: Raising Window Glass To Closed Position
Courtesy of FORD MOTOR CO.

7. Disconnect the rear door window regulator motor electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup
