Ford F150 Pickup. Instruction - part 296

Fig. 106: Identifying Power Window Motor Bolts
Courtesy of FORD MOTOR CO.

7. To access the power window motor bolts, use a 19 mm (3/4 in) hole saw with a 8 mm (1/4 in) pilot to

drill three holes at the existing drill dimples on the door.

8. Remove the power window motor bolts and remove the motor.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 107: Removing Power Window Motor Bolts
Courtesy of FORD MOTOR CO.

9. To install, reverse the removal procedure.

z

Cycle the window glass to make sure the gears engage.

FRONT DOOR WINDOW REGULATOR

Special Tool(s)



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 108: Identifying Front Door Window Regulator Special Tool(s)
Courtesy of FORD MOTOR CO.

Removal and Installation

All vehicles

1. Remove the door speaker. Refer to SPEAKERS -- DOOR MOUNTED .

SuperCrew

2. Remove the screws and the trim panel brace.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 109: Removing Screws And Trim Panel Brace
Courtesy of FORD MOTOR CO.

All vehicles

3. Remove the front door water shield.

4. Lower the window glass.

5. Remove the window glass to regulator nuts.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup
