Fig. 70: Removing Inside Glass Weatherstrip
Courtesy of FORD MOTOR CO.

5. Lower the window glass to the bottom of the door frame and release it from the window run.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 71: Releasing Window Glass From Window
Courtesy of FORD MOTOR CO.

6. Remove the window glass.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 72: Removing Window Glass
Courtesy of FORD MOTOR CO.

7. To install, reverse the removal procedure.

REAR WINDOW GLASS



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Removal

Vehicles with rear bench seat

1. Remove the rear seat back.

1. Remove the bolts.

2. Lift up to remove the rear seat back.

Fig. 73: Removing Rear Seat Back
Courtesy of FORD MOTOR CO.

Vehicles with rear bucket seats

2. Position the rear seats forward.

3. Remove the rear center console. Refer to REAR DOOR WINDOW GLASS - SUPERCREW .

4. Remove Rear Trim Panel

1. Remove the four pin-type retainers.

2. Remove the three bolts and one nut.

NOTE:

RH side shown, LH side similar. Remove the rear trim panel.
