Fig. 74: Removing Rear Trim Panel
Courtesy of FORD MOTOR CO.

All vehicles

5. Position aside the safety belt guides.

1. Lift up on the safety belt guide cover.

2. Remove the safety belt guide bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 75: Positioning Aside Safety Belt Guides
Courtesy of FORD MOTOR CO.

6. Remove the upper rear corner trim panels.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 76: Removing Upper Rear Corner Trim Panels
Courtesy of FORD MOTOR CO.

7. Remove the coat hooks.

1. Remove the two screws.

2. Remove the two coat hooks.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 77: Removing Coat Hooks
Courtesy of FORD MOTOR CO.

8. If equipped, remove the dome lamp.

1. Carefully pry the lens out of the dome lamp.

2. Remove the dome lamp screws.

3. Remove the dome lamp.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup
