2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 62: Installing Rear Window Frame And Glass
Courtesy of FORD MOTOR CO.

2. Tighten the nuts to specification.

3. Install the rear door window garnish.

4. If equipped, install the rear door window latch screws.

Fig. 63: Installing Rear Door Window Latch Screws
Courtesy of FORD MOTOR CO.

FRONT DOOR WINDOW GLASS

Removal and Installation

All vehicles



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



1. Remove the front door trim panel. Refer to FRONT DOOR TRIM PANEL .

SuperCrew

2. Remove the screws and trim panel brace.

Fig. 64: Removing Screws And Trim Panel Brace
Courtesy of FORD MOTOR CO.

All vehicles

3. Position the front door water shield aside.

4. Lower the window glass to access the two window glass to regulator nuts.

5. Remove the inside glass weatherstrip.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Glass, Frames and Mechanisms - F150 Pickup



Fig. 65: Removing Inside Glass Weatherstrip
Courtesy of FORD MOTOR CO.

6. Remove the rear glass channel bolt and lift the channel.
