Fig. 374: Releasing Trim Positioning Tabs And Inboard Latch Trim Cover
Courtesy of FORD MOTOR CO.

8. Remove the outboard latch trim screw cover.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 375: Removing Outboard Latch Trim Screw Cover
Courtesy of FORD MOTOR CO.

9. Remove the outboard latch trim screw.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 376: Removing Outboard Latch Trim Screw
Courtesy of FORD MOTOR CO.

10. Remove the outboard trim cover.

1. Remove the screw.

2. Release the positioning tabs.

3. Remove the outboard trim cover.

CAUTION: Excessive force can damage the positioning tabs.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 377: Removing Outboard Trim Cover
Courtesy of FORD MOTOR CO.

NOTE:

To aid installation, note the way the child safety seat tether anchor is tied
to the seat backrest frame.
