Fig. 366: Installing Head Restraint Rod Guides
Courtesy of FORD MOTOR CO.

14. Install the head restraint rod guides.

15. Install the head restraint.

1. Insert the head restraint rods into the rod guides.

2. Press release button and push the head restraint rod past its stop position.

3. Using a flat-blade screwdriver, press the release tab on the second head restraint rod guide and push

head restraint rod into the rod guide.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 367: Installing Head Restraint
Courtesy of FORD MOTOR CO.

16. Install the front seat backrest. Refer to FRONT SEAT BACKREST-SEAT INTEGRATED

RESTRAINTS (SIR) .

17. Install the front seat. Refer to FRONT SEAT-WITH SEAT INTEGRATED RESTRAINTS (SIR) .

18. Reactivate the supplemental restraint system (SRS) deactivation/reactivation procedure. Refer to

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEACTIVATION AND REACTIVATION .

WARNING:

To reduce the risk of serious personal injury, read and follow all
warnings, cautions, notes and instructions in the front seat removal
and installation procedure.

WARNING:

To reduce the risk of serious personal injury, read and follow all
warnings, cautions, notes and instructions in the supplemental
restraint system (SRS) deactivation/reactivation procedure.

WARNING:

The restraint system diagnostic tool is for restraint system service
only. Remove from the vehicle prior to road use. Failure to remove
could result in injury and possible violation of vehicle safety



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



19. With all the restraint system diagnostic tools removed, prove out the supplemental restraint system (SRS).

Refer to SYSTEM OPERATION CHECK .

REAR SEAT BACKREST - SUPERCAB

Disassembly and Assembly

1. Remove the seat backrest. Refer to REAR SEAT-SUPERCAB .

2. Unclip the J-clips.

Fig. 368: Identifying Unclip J-Clips
Courtesy of FORD MOTOR CO.

3. Remove the foam pad and upholstery from the seat backrest frame.

4. Remove the upholstery from the foam pad.

5. To assemble, reverse the disassembly procedure.

REAR SEAT BACKREST - SUPERCREW 60 PERCENT

Disassembly and Assembly

1. Remove the seat. Refer to REAR SEAT-60 PERCENT, SUPERCREW .

2. Remove the seat backrest. Refer to REAR SEAT BACKREST-SUPERCREW 60 PERCENT .

3. Remove the screws.

standards.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 369: Removing Screws
Courtesy of FORD MOTOR CO.

4. To assemble, reverse the disassembly procedure.

REAR SEAT BACKREST - 40 PERCENT AND QUAD BUCKET, SUPERCREW

Disassembly and Assembly

1. Remove the seat backrest. Refer to REAR SEAT Backrest-40 PERCENT AND QUAD BUCKET,

SUPERCREW .

2. While pressing the release button, pull the headrest from the seat backrest.
