Fig. 358: Installing Safety Belt Retractor And Retractor Bolt
Courtesy of FORD MOTOR CO.

Vehicles with heated seats

5. Install the backrest heated seat element to the foam pad, if necessary.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 359: Installing Backrest Heated Seat Element To Foam Pad
Courtesy of FORD MOTOR CO.

All vehicles

6. Install the seat backrest foam pad.

7. Position the seat trim cover on the foam pad. Install the hog rings in the center of the seat trim cover.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 360: Installing Hog Rings In Center Of Seat Trim Cover
Courtesy of FORD MOTOR CO.

8. Stretch the seat trim cover over the backrest foam while attaching the hook and loop fasteners.

9. Attach the inner backrest J-clip.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 361: Attaching Inner Backrest J-Clip
Courtesy of FORD MOTOR CO.

10. Attach the backrest J-clip.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
