5. To assemble, reverse the disassembly procedure.

FRONT SEAT BACKREST - FRONT BENCH

Disassembly and Assembly

1. Disassemble the seat. Refer to SEAT-FRONT BENCH .

2. Remove the seat recliner dump handle.

Fig. 321: Removing Seat Recliner Dump Handle
Courtesy of FORD MOTOR CO.

3. Unclip the J-clip retainer.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 322: identifying Unclip J-Clip Retainer
Courtesy of FORD MOTOR CO.

4. Invert the seat back trim cover to the first row of hog rings.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 323: Identifying Invert Seat Back Trim Cover
Courtesy of FORD MOTOR CO.

5. Remove the six hog rings.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 324: Removing Six Hog Rings
Courtesy of FORD MOTOR CO.

6. Invert the seat back trim cover to the second row of hog rings.

Fig. 325: identifying Invert Seat Back Trim Cover
Courtesy of FORD MOTOR CO.

7. Remove the seat back trim cover.

1. Remove the four hog rings.
