Fig. 317: Removing Bolt And Retractor
Courtesy of FORD MOTOR CO.

15. Remove the bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 318: Removing Bolts
Courtesy of FORD MOTOR CO.

16. To assemble, reverse the disassembly procedure.

REAR SEAT CUSHION - 40 PERCENT AND QUAD BUCKET, SUPERCREW

Disassembly and Assembly

1. Remove the seat cushion. Refer to REAR SEAT CUSHION-40 PERCENT AND QUAD BUCKET,

SUPERCREW .

2. Release the J-clips.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 319: Releasing J-Clips
Courtesy of FORD MOTOR CO.

3. Remove the upholstery.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 320: Removing Upholstery
Courtesy of FORD MOTOR CO.

4. Remove the pad from the seat cushion frame.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
