1. Remove the seat track. Refer to SEAT TRACK-MANUAL .

2. Remove the two front seat riser supports.

1. Remove the four nuts.

2. Remove the two front seat riser supports and the riser bracket.

Fig. 274: Removing Two Front Seat Riser Supports
Courtesy of FORD MOTOR CO.

3. Remove instruction seat track release bar (603A86).

1. Remove the bolts.

2. If equipped, drill out the rivet.

3. Remove the instruction seat track release bar.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 275: Removing Instruction Seat Track Release Bar
Courtesy of FORD MOTOR CO.

Assembly

1. Install instruction seat track release bar.

1. Position instruction seat track release bar onto the front seat track.

2. Install the three bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 276: Installing Instruction Seat Track Release Bar
Courtesy of FORD MOTOR CO.

2. Install the two front seat risers.

1. Position the two front seat risers and the riser bracket.

2. Install the four nuts.

NOTE:

Inspect the seat risers and verify that plastic isolators are in place.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 277: Installing Two Front Seat Risers
Courtesy of FORD MOTOR CO.

3. Install the seat track. Refer to SEAT TRACK-MANUAL .

FRONT SEAT CUSHION - FRONT BENCH

Disassembly

1. Disassemble the front bench seat. Refer to SEAT-FRONT BENCH .

2. Unclip the seat cushion trim cover J-clips.
