Fig. 270: Connecting Lumbar Support Adjuster To Adjuster Cable
Courtesy of FORD MOTOR CO.

4. Install the lumbar support adjuster.

1. Position the lumbar support adjuster.

2. Install the two screws.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 271: Installing Lumbar Support Adjuster
Courtesy of FORD MOTOR CO.

5. Install the lumbar support adjuster knob.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 272: Installing Lumbar Support Adjuster Knob
Courtesy of FORD MOTOR CO.

6. Install the safety belt buckle.

1. Install the safety belt buckle.

2. Install the safety belt fastener.

3. Connect the safety belt warning indicator switch electrical connector.

NOTE:

Instruction seat is shown, power seat is similar.

NOTE:

Apply Ford Threadlock 262 E2FZ-19554-B meeting Ford specification
WSK-M2G351-A6 or equivalent to fasteners when installing safety belt
buckle or retractor assemblies.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 273: Installing Safety Belt Buckle
Courtesy of FORD MOTOR CO.

7. Install the front seat track. Refer to SEAT TRACK-MANUAL or SEAT TRACK-POWER .

8. Check the restraint system for correct operation.

SEAT - TRACK, MANUAL

Disassembly
