Ford F150 Pickup. Instruction - part 235

Fig. 278: Identifying Unclip Seat Cushion Trim Cover J-Clips
Courtesy of FORD MOTOR CO.

3. Remove the safety belt opening hog rings.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 279: Removing Safety Belt Opening Hog Rings
Courtesy of FORD MOTOR CO.

4. Position the seat cushion trim cover to access the hog rings.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 280: Identifying Position Of Seat Cushion Trim Cover To Access Hog Rings
Courtesy of FORD MOTOR CO.

5. Remove the seat cushion trim cover.

1. Remove the hog rings.

2. Remove the seat cushion trim cover.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 281: Removing Seat Cushion Trim Cover
Courtesy of FORD MOTOR CO.

6. Remove the seat cushion frame from the seat cushion foam.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup
