Fig. 177: Removing Seat Track To Seat Cushion Front Bolts
Courtesy of FORD MOTOR CO.

3. Remove the seat track assembly (61709).

1. Position the seat track forward.

2. Remove the seat track rear bolts.

3. Remove the seat track assembly.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 178: Removing Seat Track Assembly
Courtesy of FORD MOTOR CO.

Installation

1. Install the seat track.

1. Position the seat track.

2. Loosely install the seat track rear bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 179: Installing Seat Track
Courtesy of FORD MOTOR CO.

2. Install the seat track front bolts.

1. Position the seat track rearward.

2. Install the seat track front bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 180: Installing Seat Track Front Bolts
Courtesy of FORD MOTOR CO.

3. Tighten the seat track rear bolts.
