Fig. 169: Inserting Upholstery Clip Into Seat Backrest
Courtesy of FORD MOTOR CO.

6. Remove the upholstery (66601).

7. Remove the pushpins.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 170: Removing Pushpins
Courtesy of FORD MOTOR CO.

8. Remove the seat backrest pad, then the bolts (66801).



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 171: Removing Seat Backrest Pad And Bolts
Courtesy of FORD MOTOR CO.

9. To install, reverse the removal procedure.

z

Check the active restraint system for correct operation. Refer to SAFETY BELT SYSTEM .

REAR SEAT BACKREST - 40 PERCENT AND QUAD BUCKET, SUPERCREW

Removal and Installation

1. Remove the seat from the vehicle. Refer to REAR SEAT-40 PERCENT AND QUAD BUCKET,

SUPERCREW .

2. Release the trim cover J-clip. Pull the child safety seat tether anchor out of the J-clip.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Seating - F150 Pickup



Fig. 172: Releasing Trim Cover J-Clip
Courtesy of FORD MOTOR CO.

3. Position the back of the trim cover up to remove the staples.
