Ford F150 Pickup. Instruction - part 1963

Fig. 14: Installing 4WD Indicator Switch
Courtesy of FORD MOTOR CO.

SHIFT LEVER

Special Tool(s)



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup



Fig. 15: Identifying Special Tool(s)
Courtesy of FORD MOTOR CO.

Removal

1. Remove the gearshift lever boot.

1. Remove the gearshift lever knob.

2. Remove the four gearshift lever boot screws.

3. Remove the gearshift lever boot.



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup



Fig. 16: Removing Gearshift Lever Boot
Courtesy of FORD MOTOR CO.

2. Remove the gearshift lever cover.

1. Remove the four gearshift lever cover bolts.

2. Remove the gearshift lever cover.



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup



Fig. 17: Removing Gearshift Lever Cover
Courtesy of FORD MOTOR CO.

3. Remove the upper gearshift lever.

1. Remove the upper gearshift lever bolt.

2. Remove the upper gearshift lever.
