Ford F150 Pickup. Instruction - part 1962

Fig. 10: Index Marking Rear Driveshaft Yoke
Courtesy of FORD MOTOR CO.

2. Remove the rear driveshaft. For additional information, refer to DRIVESHAFT & UNIVERSAL

JOINTS .

3. Using a suitable tool, remove the oil seal.



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup



Fig. 11: Removing Oil Seal
Courtesy of FORD MOTOR CO.

Installation

1. To install, reverse the removal procedure.

z

Using the special tool, install the oil seal.



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup



Fig. 12: Installing Oil Seal
Courtesy of FORD MOTOR CO.

SHIFT SWITCH - 4WD INDICATOR

Removal



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup



1. Raise and support the vehicle. For additional information, refer to JACKING & HOISTING .

2. Remove the 4WD indicator switch.

1. Disconnect the 4WD indicator switch electrical connector.

2. Remove the 4WD indicator switch.

Fig. 13: Removing 4WD Indicator Switch
Courtesy of FORD MOTOR CO.

Installation

1. To install, reverse the removal procedure.



2003 Ford Pickup F150

2003 TRANSMISSIONS Transfer Case - F150 Pickup
