Ford F150 Pickup. Instruction - part 141

Fig. 119: Removing Exterior Rear Door Handle
Courtesy of FORD MOTOR CO.

7. To install, reverse the removal procedure.

INTERIOR DOOR HANDLE - FRONT

Removal and Installation

1. Disconnect the battery ground cable.

2. Remove the front door trim panel (23942). Refer to FRONT DOOR TRIM PANEL .

3. Position the interior door handle aside.

1. Remove the screw.

2. Position the interior door handle aside.

NOTE:

Make sure the actuating rods are in the relaxed position before engaging
the clip.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 120: Positioning Interior Door Handle
Courtesy of FORD MOTOR CO.

4. Disconnect the interior door handle cable.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 121: Disconnecting Interior Door Handle Cable
Courtesy of FORD MOTOR CO.

5. To install, reverse the removal procedure.

INTERIOR DOOR HANDLE - REAR, SUPERCREW

Removal and Installation

1. Remove the rear door trim panel (23942). Refer to TRIM PANEL -- REAR DOOR .

2. Position the interior door handle aside.

1. Remove the screw.

2. Position the interior door handle aside.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 122: Positioning Interior Door Handle Aside
Courtesy of FORD MOTOR CO.

3. Disconnect the interior door handle cable.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup
