Fig. 123: Disconnecting Interior Door Handle Cable
Courtesy of FORD MOTOR CO.

4. To install, reverse the removal procedure.

INTERIOR DOOR HANDLE - REAR, F-150

Removal

1. Remove the rear door trim panel. Refer to TRIM PANEL -- REAR DOOR .

2. Remove the rear door radio speaker (18808).

1. Remove the screws.

2. Disconnect the electrical connector.

3. Remove the rear door radio speaker.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 124: Removing Rear Door Radio Speaker
Courtesy of FORD MOTOR CO.

3. Remove the watershield.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 125: Removing Watershield
Courtesy of FORD MOTOR CO.

4. Remove the interior rear door handle.

1. Remove the nuts.

2. Remove the interior rear door handle.



2003 Ford Pickup F150

2003 ACCESSORIES AND EQUIPMENT Handles, Locks, Latches and Entry Systems - F150 Pickup



Fig. 126: Removing Interior Rear Door Handle
Courtesy of FORD MOTOR CO.

5. Remove the rear door interior handle remote control.

1. Rotate the rear door interior handle remote control downward.

2. Disconnect the rear door handle remote control rod.
