Fig. 55: Connecting Inertia Fuel Shutoff Switch Electrical Connector
Courtesy of FORD MOTOR CO.

17. Install the instrument panel reinforcement bolt below the LH corner of the cigar lighter and power point.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 56: Installing Instrument Panel Reinforcement Bolt
Courtesy of FORD MOTOR CO.

18. Install the instrument panel bolts through the steering column opening.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 57: Installing Instrument Panel Bolts Through Steering Column Opening
Courtesy of FORD MOTOR CO.

19. Position the steering column.

z

Install the four steering column support nuts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 58: Positioning Steering Column
Courtesy of FORD MOTOR CO.

20. If equipped, connect the transmission range indicator to the steering column.

1. Connect the cable.

2. Install the bolt.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup
