Fig. 35: Removing Antenna Lead-In Cable From Instrument Panel
Courtesy of FORD MOTOR CO.

40. Remove the glove compartment.

41. Remove the instrument panel bolts through the passenger side air bag module opening.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 36: Removing Instrument Panel Bolts Through Passenger Side Air Bag Module Opening
Courtesy of FORD MOTOR CO.

42. Remove the instrument panel bolt on the relay bracket.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 37: Removing Instrument Panel Bolt On Relay Bracket
Courtesy of FORD MOTOR CO.

43. Remove the instrument panel reinforcement bolt below the LH corner of the glove compartment.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 38: Removing Instrument Panel Reinforcement Bolt
Courtesy of FORD MOTOR CO.

44. Loosen the instrument panel floor brace.

1. Remove the upper instrument panel floor brace bolt.

2. Loosen the instrument panel brace bolts and nut

NOTE:

Position the carpet aside.
