Fig. 27: Lowering Steering Column
Courtesy of FORD MOTOR CO.

31. Remove the instrument panel bolts through the steering column opening.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 28: Removing Instrument Panel Bolts
Courtesy of FORD MOTOR CO.

32. Remove the instrument panel reinforcement bolt below the LH corner of the cigar lighter and power

point.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 29: Removing Instrument Panel Reinforcement Bolt
Courtesy of FORD MOTOR CO.

33. Disconnect the inertia fuel shutoff switch electrical connector.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup



Fig. 30: Disconnecting Inertia Fuel Shutoff Switch Electrical Connector
Courtesy of FORD MOTOR CO.

34. Remove the RH ground bolts.



2003 Ford Pickup F150

2003 ACCESSORIES AND BODY, CAB Instrument Panel and Console - F150 Pickup
