DESCRIPTION
SPECIFICATION
Required clearance, Oil pump drive sprocket
0.10-0.23 mm (0.004-0.009 in.) The select shim is
equal to the oil pump drive sprocket measurement one
plus the oil pump drive sprocket measurement two
minus 0.16 mm (0.0065 in.).
Torque converter installed depth
at least 13 mm
TORQUE SPECIFICATIONS
DESCRIPTION
N-m
Ft. Lbs.
In. Lbs.
bolts, drive belt assembly - to - transaxle case
45
33
-
Bolt, Detente spring to case
7
-
61
Bolts, oil pump - to - transaxle case
19
14
168
Bolt, oil pump - to - transaxle case (out side )
28
20
247
Bolts, Valve body assembly - to - case
8
-
70
Nut, Valve body manual lever - to - manual shaft
22
16
194
Bolts, Oil strainer to valve body
8
-
70
Bolts, oil pan - to - transaxle case
8
-
70
Bolts, baffle plate
6
-
52
Bolts, oil pump cover
26
19
230
Bolts, Bracket oil pump cover - to oil pump
26
19
230
Bolts, Baffle plate
26
19
230
Bolts, Baffle plate at oil pump driven sprocket
6
-
52
Bolts, Converter housing - to - transaxle case
45
33
398
Bolts, TRS
6
-
49
Nut, Shift lever to manual shaft
17
13
150
Bolt, Speed input sensor - to - transaxle case
6
-
52
Bolt, Speed output sensor - to - transaxle case
6
-
52
Bolts, Fluid cooler - to - transaxle case
4
-
37
Bolts, transmission bell housing - to - engine
108
80
-
Bolts, Transmission cross member
75
55
-
Nut, Rear mount through bolt
75
55
-
Bolts, Rear mount to transaxle
75
55
-
Bolts, Torque converter
88
65
-
Bolts, Bell housing
108
80
-
Bolts, Upper mount
75
55
-
Nut, Upper mount through bolt
75
55
-
Bolts, Throttle body support bracket
11
-
105
Nut, Shiftier cable
11
-
105
Bolts, Transmission fill tube
9
-
79
Nut, Reduction gear
250
185
-
Bolts, Shiftier - to - floor
70
52
-
Bolts, Bracket to Valve Body
8
70
-
PM
AUTOMATIC - CVT-SERVICE INFORMATION
21 - 399
