Fig. 567: Removing/Installing Sunroof Glass Panel
Courtesy of CHRYSLER LLC

1. Slide sunshade rearward to the open position.

2. Move the glass panel (2) to the closed position.

3. Remove the four glass panel screws (1).

4. Lift off glass panel and remove from vehicle.

INSTALLATION

GLASS - SUNROOF

1 - SCREWS
2 - GLASS PANEL
3 - MODULE ASSEMBLY



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 568: Removing/Installing Sunroof Glass Panel
Courtesy of CHRYSLER LLC

1. Position glass panel (2) on to mechanism lift arm.

2. Start the four attaching screws (1).

3. Center glass in opening by running a business card around the glass.

4. Adjust glass panel. See ADJUSTMENTS.

ADJUSTMENTS

GLASS - SUNROOF

1 - SCREWS
2 - GLASS PANEL
3 - MODULE ASSEMBLY



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 569: Removing/Installing Sunroof Glass Panel
Courtesy of CHRYSLER LLC

1. Move the sunshade rearward to the open position.

2. Move the sunroof glass panel to the fully closed position.

3. Adjust the glass one corner at a time.



Loosen four glass screws (1).



Lift glass assembly and align the top of the glass panel to the top of the roof panel.



Tighten screw to 3.5 N.m (31 in. lbs.).



Repeat steps a. and b. for each corner of the glass panel.



When properly adjusted, the front of the glass panel is flush to 2 mm (0.78 in.) lower than the roof
surface and the rear edge of the glass panel is flush to 2 mm (0.78 in.) higher than the roof surface.

1 - SCREWS
2 - GLASS PANEL
3 - MODULE ASSEMBLY



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 570: Checking Sunroof Front Height
Courtesy of CHRYSLER LLC

NOTE:

When properly adjusted, the front of the glass panel (3) is flush to 2 mm
(0.78 in.) lower than the roof surface (2).
