Fig. 557: Removing/Installing Windshield
Courtesy of CHRYSLER LLC

9. Cut urethane bonding from around windshield using a suitable sharp cold knife. A pneumatic cutting

device can be used if available.

10. Remove windshield from vehicle.

INSTALLATION

GLASS - WINDSHIELD

Fig. 558: Removing/Installing Windshield
Courtesy of CHRYSLER LLC

WARNING:

Review all warnings and cautions in this group before preceding with
installation.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



The windshield fence should be cleaned of old urethane bonding material. Support spacers should be cleaned
and properly installed on weld studs or repair screws at bottom of windshield opening.

1. Place replacement windshield into windshield opening. Position glass in the center of the opening against

the support spacers. Mark the glass at the support spacers with a grease pencil or masking tape and ink
pen to use as a reference for installation. Remove replacement windshield from windshield opening.

Fig. 559: Windshield Spacers
Courtesy of CHRYSLER LLC

2. Position the windshield inside up on a suitable work surface with two padded, wood 10 cm by 10 cm by

50 cm (4 in. by 4 in. by 20 in.) blocks, placed parallel 75 cm (2.5 ft.) apart.

3. Clean inside of windshield with Mopar® Glass Cleaner and lint-free cloth.

4. Apply clear glass primer 25 mm (1 in.) wide around edge of windshield. Wipe with clean/dry lint-free

cloth.

5. Apply black-out primer 15 mm (.75 in.) wide on top and sides of windshield and 25 mm (1 in.) on bottom

of windshield. Allow at least three minutes drying time.

6. Position adhesive backed spacers at the edge of the windshield opening.

7. Align the dot on the upper molding to the tick mark in the center of the glass and install upper molding

onto windshield.

8. Apply a 10 mm (0.4 in.) bead of urethane around perimeter of windshield along the inside of the

moldings. Apply two beads along the bottom edge.

9. Apply fence primer around the perimeter of the windshield opening fence. Allow at least 18 minutes

CAUTION: Open a window before installing windshield. This will avoid pressurizing

the passenger compartment. If a door or swing gate flip-up glass is
slammed before urethane is cured, water leaks can result.

CAUTION: Protect all painted and trimmed surfaces from coming in contact with

urethane or primers.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



drying time.

Fig. 560: Removing/Installing Windshield
Courtesy of CHRYSLER LLC

10. With aid of a helper, position windshield over windshield opening. Align reference marks at bottom of

windshield to support spacers.

11. Slowly lower windshield glass to windshield opening fence. Guide top molding into proper position if

necessary. Push windshield inward to fence spacers at bottom and until top molding is flush to roof line.

12. Clean excess urethane from exterior with Mopar® Super Clean or equivalent.

Fig. 561: Push Pin, Windshield A-Pillar Molding & Clips
Courtesy of CHRYSLER LLC

13. Install the windshield A-pillar molding (2) and clips (3) to the windshield A-pillar.

14. Install the push pin (1).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 562: Cowl Grille, Push Pins, Hood Seal & Body
Courtesy of CHRYSLER LLC

15. Position the cowl grille (1) and engage the clips to the bottom of the windshield.

16. Install the four push pins (2) through the cowl grille (1) and into the body (4).

17. Install the hood seal (3).

18. Install the wiper arms, refer to INSTALLATION .

19. Install inside rear view mirror, see INSTALLATION.

20. After urethane has cured, water test windshield to verify repair.

SUNROOF

DESCRIPTION

SUNROOF

The sunroof features a power sliding glass panel and a sunshade which can be manually positioned anywhere
along its travel, rearward of glass panel front edge.

The sunroof is electrically operated from two switches located on the windshield header, rearward of the map
lamp. To operate the sunroof the ignition switch must be in either the Accessory or On/Run position. One
switch (vent) is a push button type and opens the sunroof to the vent position only. The other switch
(open/close) is a rocker type for opening and closing the sunroof. Pressing and releasing the open button once
the sunroof will express open and the wind deflector will raise. If the button is pressed a second time the
sunroof will stop in that position. Pressing and releasing the button while the sunroof is in the open position will
cause the sunroof to express close and the wind deflector will lower. If the button is pressed a second time the
sunroof will stop in that position.

WARNING:

Keep fingers and other body parts out of sunroof opening at all times.
