Fig. 107: Release Rod & Swing Clips
Courtesy of CHRYSLER LLC

5. Install the release rod (1) then engage the two swing clips (2).

Fig. 108: Removing/Installing Slide Fork
Courtesy of CHRYSLER LLC

6. Install the slide fork to the latch bracket.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 109: Identifying Carrier Plate Slots
Courtesy of CHRYSLER LLC

7. Install the latch bracket assembly to the carrier plate slots (1) then slide the latch bracket until fully

seated.

Fig. 110: Disconnecting/Connecting Latch Electrical Connector
Courtesy of CHRYSLER LLC

8. Connect the latch electrical connector.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 111: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

9. Install the carrier plate. See INSTALLATION.

Fig. 112: Adjusting Latch
Courtesy of CHRYSLER LLC

10. Adjust the latch as needed. See ADJUSTMENTS.

ADJUSTMENTS

LATCH - FRONT DOOR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 113: Adjusting Latch
Courtesy of CHRYSLER LLC

1. Locate the access hole and remove tape covering adjustment hole.

2. Insert a 5/32" hex-wrench through hole and into adjustment screw (2). Loosen screw.

3. Operate outside handle several times to release any restriction because of mis-alignment.

4. Tighten adjustment screw to 4 N.m (35 in. lbs.).

5. Test handle for proper operation.

STRIKER - FRONT DOOR LATCH

REMOVAL

STRIKER - FRONT DOOR LATCH

Fig. 114: Striker Loop, Bolts, Striker & B-Pillar
Courtesy of CHRYSLER LLC
