Fig. 91: Upper/Lower Hinges, Door & Nuts
Courtesy of CHRYSLER LLC

1. Remove the front door. See REMOVAL.

Fig. 92: Removing/Installing Front Door Hinge
Courtesy of CHRYSLER LLC

2. Remove the four bolts (2) that secure the upper door hinge (1) and lower door hinge (3) to the body of the

lower A-pillar and remove the hinges.

INSTALLATION

HINGE - FRONT DOOR

NOTE:

Use a grease pencil or equivalent, mark the location of the upper (1) and
lower (3) hinge on the body of the lower A-pillar for alignment during
installation.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 93: Removing/Installing Front Door Hinge
Courtesy of CHRYSLER LLC

1. Install the upper (1) and lower (3) hinges to the B-pillar and loosely install the bolts.

2. Align the hinges on the A-pillar using the reference marks made during the removal procedure and

tighten the bolts to 26 N.m (19 ft. lbs.).

Fig. 94: Upper/Lower Hinges, Door & Nuts
Courtesy of CHRYSLER LLC

3. Install the front door. See INSTALLATION.

LATCH - FRONT DOOR

REMOVAL

LATCH - FRONT DOOR



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 95: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

1. Remove the carrier plate. See REMOVAL.

Fig. 96: Disconnecting/Connecting Latch Electrical Connector
Courtesy of CHRYSLER LLC

2. Disconnect the latch electrical connector.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 97: Carrier Plate Slots
Courtesy of CHRYSLER LLC

3. Turn the carrier plate over and slide the latch bracket assembly to remove from carrier.

Fig. 98: Removing/Installing Slide Fork
Courtesy of CHRYSLER LLC

4. Remove the slide fork from the latch bracket.
