1. Remove the bolts (2) from the striker latch (3).

2. Remove the latch striker (3) from the B-pillar (4).

INSTALLATION

STRIKER - FRONT DOOR LATCH

Fig. 115: Striker Loop, Bolts, Striker & B-Pillar
Courtesy of CHRYSLER LLC

1. Install the striker (3) to the B-pillar (4).

2. Install the bolts (2) and tighten to 26 N.m (19 ft. lbs.).

3. Adjust the door as necessary. See ADJUSTMENTS, and for fit SPECIFICATIONS.

CYLINDER - FRONT DOOR LOCK

REMOVAL

CYLINDER - FRONT DOOR LOCK

NOTE:

The striker needs to be properly orientated to the B-pillar. The striker loop (1)
must be installed to the inboard side of the B-pillar.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 116: Gasket, Door Lock Cylinder, Door, Carrier Plate & Door Lock Cylinder Retainer
Courtesy of CHRYSLER LLC

1. Remove carrier plate from door, see REMOVAL.

2. Remove door lock cylinder retainer (5) from door lock cylinder (2).

3. Remove door lock cylinder (2) and gasket (1) from door (3).

INSTALLATION

CYLINDER - FRONT DOOR LOCK

Fig. 117: Gasket, Door Lock Cylinder, Door, Carrier Plate & Door Lock Cylinder Retainer
Courtesy of CHRYSLER LLC

1. Install lock cylinder (2) and gasket (1) to door (3).

NOTE:

The lever on the key cylinder needs to point forward.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



2. Install lock cylinder retainer (5) to door lock cylinder (2).

3. Install the carrier plate to the door, see INSTALLATION.

RUN CHANNEL - FRONT DOOR GLASS

REMOVAL

RUN CHANNEL - FRONT DOOR GLASS

Fig. 118: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

1. Remove the door carrier plate from the door, see REMOVAL.

Fig. 119: Removing/Installing Front Door Glass

NOTE:

Make sure the door lock cylinder (2) is engaged to the carrier plate (4).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Courtesy of CHRYSLER LLC

2. Remove the front door glass from the window opening in the door. See REMOVAL.

Fig. 120: Removing/Installing Run Channel
Courtesy of CHRYSLER LLC

3. Remove the run channel from the window opening in the door.

INSTALLATION

RUN CHANNEL - FRONT DOOR GLASS

Fig. 121: Removing/Installing Run Channel
Courtesy of CHRYSLER LLC

1. Install the run channel to the window opening in the door.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro
