Fig. 47: Carrier & Interior Handle
Courtesy of CHRYSLER LLC

16. Install the interior lock rod to the interior handle (2). Make sure the lock rod is positioned properly to the

carrier (1).

Fig. 48: Grommet, Interior Handle Lock Rod & Carrier
Courtesy of CHRYSLER LLC

17. Install the interior lock rod (2) into the carrier plate (3) and seat the grommet (1).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 49: Disconnecting/Installing Interior Handle Lock Rod
Courtesy of CHRYSLER LLC

18. Connect the interior handle lock rod to the latch.

Fig. 50: Inside Lock Rod, Grommet & Carrier Plate
Courtesy of CHRYSLER LLC

19. Install the inside lock rod (1) to the carrier plate (3) and seat the grommet (2).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 51: Disconnecting/Connecting Inside Lock Rod
Courtesy of CHRYSLER LLC

20. Connect the inside lock rod to the latch.

Fig. 52: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

21. Connect the outside mirror electrical connector.

22. Install the electrical connector (1) to the door (4) and connect the electrical connector.

23. Align the carrier plate (2) to the door (4).



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 53: Removing/Installing Door Latch & Latch Bracket Securing Screws
Courtesy of CHRYSLER LLC

24. Install the three screws (2) securing the door latch to the door shut face and tighten screws to 7 N.m (60

in. lbs.).

25. Install the one screw (1) attaching the latch bracket to the door shut face and tighten screw to 7 N.m (60

in. lbs.).

Fig. 54: Door Plug & Rear Exterior Handle Nut
Courtesy of CHRYSLER LLC

26. Install the rear nut (1) to the exterior handle and tighten to 4.5 N.m (40 in. lbs.).

27. Install the door plug (2) to the door.

NOTE:

The door glass must be in the full up position in order to access the rear
exterior handle nut. Use a light and a magnetic socket on the rear nut to
prevent dropping the nut into the door assembly.
