Fig. 55: Electrical Connector, Carrier Plate, Screws & Door
Courtesy of CHRYSLER LLC

28. Install the 10 screws (3) to the carrier plate (2) and tighten screws to 5.5 N.m (50 in. lbs.).

Fig. 56: Door Glass & Window Regulator Liftplate
Courtesy of CHRYSLER LLC

29. Connect the door glass (1) to the window regulator (2) by sliding the glass down into the liftplate.

30. Apply the adhesive tape to the inspection hole of the carrier plate.

NOTE:

The glass should snap into place. Make sure the glass is secure to the
liftplate by pulling up on the glass to verify.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 57: Removing/Installing Trim Panel
Courtesy of CHRYSLER LLC

31. Install the trim panel to the door. See INSTALLATION.

32. Adjust the latch assembly, see ADJUSTMENTS.

33. Connect the negative battery cable to the battery.

DOOR - FRONT

REMOVAL

DOOR - FRONT

NOTE:

Cycle the door lock, open with interior and exterior door handles and operate
the power window to make sure everything is working properly and no binding
exists.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 58: Using Battery Terminal Removal Tool To Disconnect Negative Battery Cable From Battery
Courtesy of CHRYSLER LLC

1. Loosen the battery terminal nut and use a battery terminal removal tool (2) to disconnect the negative

battery cable from the battery (1).

Fig. 59: Disconnecting/Connecting Door Harness Electrical Connector From/To Body Connector
Courtesy of CHRYSLER LLC

2. Disconnect the door harness electrical connector (1) from the body connector (2) at the A-pillar.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro



Fig. 60: Upper/Lower Hinges, Door & Nuts
Courtesy of CHRYSLER LLC

3. Support the door with a suitable lifting device.

4. Remove the nuts (4) attaching the door (2) to the upper (1) and lower (3) hinges.

5. Carefully remove the door (2) from the vehicle.

INSTALLATION

DOOR - FRONT

Fig. 61: Upper/Lower Hinges, Door & Nuts
Courtesy of CHRYSLER LLC

NOTE:

Use a grease pencil or equivalent, mark the location of the upper (1) and
lower (3) hinges on the door (2) for alignment during Reinstallation.



2007 Dodge Nitro R/T

2007 ACCESSORIES AND EQUIPMENT Body - Nitro
