 200346

3-5

Removal and installation

ACCESSORIES

ΧΦ65/75/85 series

1

8

Removing roof spoiler extension pieces
combined with fenders (cab with raised roof)
1.

Remove the attachment bolts from the upper
fender (A) and remove the fender from the
roof spoiler.

2.

Remove the attachment bolts from the lower
fender (B) and remove the fender from the
cab.

Installing roof spoiler extension pieces
combined with fenders (cab with raised roof)
1.

Fit the lower fender (B) to the cab, using the
attachment bolts.

2.

Fit the upper fender (A) to the cab, using the
attachment bolts.

K1 01 360

A

B

ACCESSORIES

3-6

©

 200346

Removal and installation

8

ΧΦ65/75/85 series

1

3.5 REMOVAL AND INSTALLATION, CORNER SPOILER

Removing corner spoiler
1.

Open the grille and remove the corner
piece (1).

2.

Remove the attachment screws (2) and
remove the corner spoiler (3) from the corner
piece.

Installing corner piece
1.

Fit the corner spoiler (3) to the corner
piece (1)

2.

Fit the corner piece (1) and close the grille.

2

3

1

2

K1 01 415

©

 200346

3-7

Removal and installation

ACCESSORIES

ΧΦ65/75/85 series

1

8

3.6 REMOVAL AND INSTALLATION, SUN VISOR ASSEMBLY

Removing sun visor assembly, day/sleeper
cab
1.

If fitted, remove the spotlights.

2.

Remove the attachment bolts from the
marker lights.

3.

Remove the attachment bolts from the
brackets and remove the sun visor complete
with brackets from the cab roof.

Installing sun visor assembly, day/sleeper
cab
1.

To fit the sun visor stress-free, loosen the
attachment bolts fastening the plastic hood
to the brackets a few strokes.

2.

Fit the sun visor complete with brackets to
the cab roof and fit the attachment bolts with
the plastic washers.

3.

Tighten the attachment bolts fastening the
plastic hood to the brackets.

4.

Fit the attachment bolts of the marker lights.

5.

If present, fit the spotlights.

Removing sun visor assembly (cab with
raised roof)
1.

If fitted, remove the spotlights.

2.

Remove the attachment bolts from the
brackets and remove the sun visor complete
with brackets from the cab.

Installing sun visor assembly (cab with raised
roof)
1.

To fit the sun visor stress-free, loosen the
attachment bolts fastening the plastic hood
to the brackets a few strokes.

2.

Fit the sun visor complete with brackets to
the cab and fit the attachment bolts with the
plastic washers.

3.

Tighten the attachment bolts fastening the
plastic hood to the brackets.

4.

If present, fit the spotlights.

ACCESSORIES

3-8

©

 200346

Removal and installation

8

ΧΦ65/75/85 series

1

3.7 REMOVAL AND INSTALLATION, SPOTLIGHTS COMPLETE WITH BRACKET

Removing spotlights complete with bracket
1.

Detach the connector behind the spotlight
bracket.

2.

Remove the attachment bolts from the
bracket and remove the bracket complete
with spotlights from the cab roof.

Installing spotlights complete with bracket
1.

Fit the bracket with spotlights to the cab and
fit the attachment bolts with the plastic
washers.

2.

Fit the connector.

3.

Check that the cable duct through the cab
roof is water-tight. If necessary, seal the
passage again.
