DAF CF65, CF75, CF85 Series . Manual - part 164

©

 200346

3-1

Removal and installation

ACCESSORIES

ΧΦ65/75/85 series

1

8

3. REMOVAL AND INSTALLATION

3.1 REMOVAL AND INSTALLATION, ROOF SPOILER (BASIC)

Removing roof spoiler (basic)
1.

Remove the four attachment nuts from the
cab roof attachment frame.

2.

Take the roof spoiler from the cab roof.

Installing roof spoiler (basic)
1.

Position the roof spoiler with attachment
frame onto the studs on the cab roof.

2.

Fit the four attachment nuts of the
attachment frame.

3.

Check the setting of the roof spoiler, see
chapter 'Inspection and adjustment".

ACCESSORIES

3-2

©

 200346

Removal and installation

8

ΧΦ65/75/85 series

1

3.2 REMOVAL AND INSTALLATION, ROOF SPOILER (AERODYNAMIC)

Removing roof spoiler (aerodynamic)
1.

Remove the four attachment nuts from the
cab roof attachment frame.

2.

Take the roof spoiler from the cab roof.

3.

Remove the attachment bolts from the roof
spoiler side sections and remove the side
sections from the cab roof.

Installing roof spoiler (aerodynamic)
1.

Fit the roof spoiler side sections on the cab
roof, using the attachment bolts.

2.

Position the roof spoiler with attachment
frame onto the studs on the cab roof.

3.

Fit the four attachment nuts of the
attachment frame.

4.

Check the setting of the roof spoiler, see
chapter 'Inspection and adjustment".

©

 200346

3-3

Removal and installation

ACCESSORIES

ΧΦ65/75/85 series

1

8

3.3 REMOVAL AND INSTALLATION, FENDER ASSEMBLY

Note:
Take care not to damage the paint. Repair any
damaged paint using the right type of paint.

Removing fender assembly (cab without roof
spoiler)
1.

Remove the attachment bolts and remove
the fender (A) from the cab.

Installing fender assembly (cab without roof
spoiler)
1.

Fit the fender (A) using the attachment bolts.

K1 01 359

A

ACCESSORIES

3-4

©

 200346

Removal and installation

8

ΧΦ65/75/85 series

1

3.4 REMOVAL AND INSTALLATION, ROOF SPOILER EXTENSION PIECES

COMBINED WITH FENDERS

Note:
Take care not to damage the paint. Repair any
damaged paint using the right type of paint.

Removing roof spoiler extension pieces
combined with fenders
1.

Remove the attachment bolts from the upper
fender (A) and remove the fender from the
roof spoiler.

2.

Remove the attachment bolts from the
middle fender (B) and remove the fender
from the roof spoiler.

3.

Remove the attachment bolts from the lower
fender (C) and remove the fender from the
cab.

Installing roof spoiler extension pieces
combined with fenders
1.

Fit the lower fender (C) to the cab, using the
attachment bolts.

2.

Fit the middle fender (B) to the cab, using the
attachment bolts.

3.

Fit the upper fender (A) to the cab, using the
attachment bolts.

A

B

C

K1 01 361
