3. Install the top catch cover (2) to the front bow (3). Tighten screws (1) to 5 N·m (44 in. lbs.). 4. Raise the convertible top. INSTALLATION - LATCH RETAINER 1. Install the latch retainer (2), shim (3), and retaining screws (4). Tighten screws to 10 N·m (89 in. lbs.). 2. Connect the latch retainer switch harness connec- tor (5). 3. Install the upper windshield trim panel. 4. Connect the universal transmitter harness connec- tor and install the lower windshield trim panel. 5. Install the dome lamp assembly. 6. Install the right and left sun visors. 7. Install both A-pillar trim panels. (Refer to 23 - BODY/INTERIOR/A-PILLAR TRIM - INSTALLA- TION). 8. Raise the convertible top. ZH CONVERTIBLE TOP 23 - 535 |
