REMOVAL - ROOF OPEN SWITCH Note: The Roof Open Switch is located underneath 1. Disconnect the negative battery cable. 2. Manually lower the convertible top (3) into the cargo compartment. (Refer to 23 - BODY/CON- 3. Secure the tonneau cover (2) in the upright posi- tion. 4. Remove the front cover retaining screws (1) and retainer (4). 5. Remove the front side weather strips (1) (right side shown, left side similar). ZH CONVERTIBLE TOP 23 - 519 |
