C227 (MK20) - BLUE (COCKPIT SIDE)

CAV

CIRCUIT

1

20DG/YL

2

20RD/WT

3

22RD/YL

3

22RD/YL (A/T)

4

22YL

5

20BR/YL

6

-

7

20BL/YL

8

-

C227 (MK20) - BLUE (ENGINE COMPARTMENT

SIDE)

CAV

CIRCUIT

1

20DG/YL

2

20RD/WT

3

20YL/BL

4

22YL

5

20BR/YL

6

-

7

20BL/YL

8

-

C228 - BLACK (BODY SIDE)

CAV

CIRCUIT

1

18PK/RD/WT

2

18BR

3

18WT

4

18GY

5

18BK

6

20BR

7

20BL

8

20BK

C228 - BLACK (DOOR SIDE)

CAV

CIRCUIT

1

18PK/RD/WT

2

18BR

3

18WT

4

18GY

5

18BK

6

20BR

7

20BL

8

20BK

ZH

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 21

C229 - BLACK (BODY SIDE)

CAV

CIRCUIT

1

16BK/BL

2

16BR/DG

3

14DG

4

14BK

5

-

C229 - BLACK (DOOR SIDE)

CAV

CIRCUIT

1

16BK/BL

1

18BK/BL

2

16BR/DG

2

18BR/DG

3

14DG

4

14BK

5

-

C230 - BLACK (BODY SIDE)

CAV

CIRCUIT

1

18PK/RD/WT

2

18BR

3

18WT

4

18GY/VT

5

18BK/VT

6

-

7

-

8

-

C230 - BLACK (DOOR SIDE)

CAV

CIRCUIT

1

18PK/RD/WT

2

18BR

3

18WT

4

18GY

5

18BK

6

-

7

-

8

-

8W - 80 - 22

8W-80 CONNECTOR PIN-OUTS

ZH

C231 - BLACK (BODY SIDE)

CAV

CIRCUIT

1

16BK/PK

2

16BR/YL

3

14DG/WT

4

14BK/WT

5

-

C231 - BLACK (DOOR SIDE)

CAV

CIRCUIT

1

18BK/BL

1

16BK/BL

2

18BR/DG

2

16BR/DG

3

14DG

4

14BK

5

-

C232 - RED (BODY SIDE)

CAV

CIRCUIT

1

20VT

2

20DG

C232 - RED (COCKPIT SIDE)

CAV

CIRCUIT

1

20VT

2

20DG

C300 (ZH27) - NATURAL (BODY SIDE)

CAV

CIRCUIT

1

-

2

20BR/BL

3

20BR/VT

4

20BK/VT

5

16BK/DG

6

16RD/DG

7

-

8

-

ZH

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 23

C300 (ZH27) - NATURAL (SPOILER SIDE)

CAV

CIRCUIT

1

-

2

20BR/BL

3

20BR/VT

4

20BK/VT

5

16BK/DG

6

16RD/DG

7

-

8

-

C301 (ZH27) - BLACK (BODY SIDE)

CAV

CIRCUIT

1

14BK

2

20BR/BK

3

20BR/BL

4

-

C301 (ZH27) - BLACK (REAR WINDOW DEFOG-

GER SIDE)

CAV

CIRCUIT

1

14BK

2

20BK

3

20BK

4

-

C302 (ZH27) - BLACK (BODY SIDE)

CAV

CIRCUIT

1

16RD/WT (EXCEPT SRT)

2

16BR/WT (EXCEPT SRT)

3

20BR/GY (EXCEPT SRT)

4

20BR/YL (EXCEPT SRT)

5

20BK/BL

6

18GY/VT

7

18GY/YL

8

14BR
