Chrysler Crossfire. Manual - part 439

C105 - BLACK (ENGINE COMPARTMENT SIDE)

CAV

CIRCUIT

1

18BR/RD

2

20YL/RD

3

20RD/YL

4

-

C106 - BLACK (ENGINE COMPARTMENT SIDE)

CAV

CIRCUIT

1

20BR/VT

2

12BK (SRT)

3

18BL/DG

4

16BK/YL

5

20BL

6

14VT/WT

7

-

8

-

C106 - BLACK (ENGINE SIDE)

CAV

CIRCUIT

1

20BR/VT (EXCEPT SRT)

1

20GY/BL (SRT)

2

12RD/WT (SRT)

3

18BL/DG

4

16BK/YL

5

18BL

6

14VT

7

-

8

-

C200 (MK20) - BLACK (COCKPIT SIDE)

CAV

CIRCUIT

1

20BR/VT

2

20BR/DG

3

20BR/RD

4

-

5

16VT

6

18BK/WT

7

18BK/DG

8

18GY

ZH

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 13

C200 (MK20) - BLACK (ENGINE COMPARTMENT

SIDE)

CAV

CIRCUIT

1

20BR/VT

2

20BR/DG

3

20BR/RD

4

18BL/DG

5

20VT

5

16VT (A/T)

6

18BK/WT

7

18BK/DG

8

18GY

C200 (MK25) - BLACK (COCKPIT SIDE)

CAV

CIRCUIT

1

18BK/DG

2

16VT

3

18BK/WT

4

22BK/BL

4

22BK/BL

5

18RD/DG

5

18RD/DG

6

22RD/YL

6

22RD/YL

7

-

8

-

C200 (MK25) - BLACK (ENGINE COMPARTMENT

SIDE)

CAV

CIRCUIT

1

18BK/DG

1

18BK/DG (EUROPE)

2

16VT

2

20VT

3

18BK/WT

3

18BK/WT (EUROPE)

4

22BK/BL

4

20BK/BL (EXCEPT EXPORT)

5

18RD/DG

6

20RD/YL

7

-

8

-

8W - 80 - 14

8W-80 CONNECTOR PIN-OUTS

ZH

C201 - BLACK (BODY SIDE)

CAV

CIRCUIT

1

20YL/BL (MK20)

1

20DG (MK25)

2

20BR (MK20)

2

20WT (MK25)

3

20RD/DG

4

20BK/RD/WT (MK20)

4

20BR (MK25)

5

20BR (MK20)

5

20BL/YL (MK25)

6

20BK/PK/WT (MK20)

6

20BK/DG (MK25)

7

20GY/YL (M/T)

8

20BL

9

20BR

10

20YL

11

20BR

12

20BK/BL

13

20DG/VT

14

20BL/DG

15

20BK/RD (MK20)

16

20BK/YL

17

20RD/WT (MK20)

17

22YL (MK25)

18

20RD/YL (MK20)

18

20DG/BK (MK25)

C201 - BLACK (ENGINE COMPARTMENT SIDE)

CAV

CIRCUIT

1

20YL/BL (MK20)

1

20DG (MK25)

2

20BR (MK20)

2

20WT (MK25)

3

20RD/DG

4

20BK/RD/WT (MK20)

4

20BR (MK25)

5

20BR (MK20)

5

20BL/YL (MK25)

6

20BK/PK/WT (MK20)

6

20BK/DG (MK25)

7

20GY/YL (M/T)

8

20BL

9

20BR

10

20YL

11

20BR

12

20BK/BL

13

20DG/VT

14

20BL/DG

15

20BK/RD (MK20)

16

20BK/YL

17

20RD/WT (MK20)

17

22YL (MK25)

18

20RD/YL (MK20)

18

20DG/BK (MK25)

ZH

8W-80 CONNECTOR PIN-OUTS

8W - 80 - 15

C206 - BLACK (BODY SIDE)

CAV

CIRCUIT

1

22BK/RD

2

20BL

3

20BK

4

20BR/GY

5

20BK/WT

6

-

7

22RD/YL (A/T)

8

22DG

C206 - BLACK (COCKPIT SIDE)

CAV

CIRCUIT

1

22BK/RD

2

20BL

3

20BK

4

20BR/GY

5

20BK/WT

5

22BK/WT

6

-

7

22RD/YL

8

22DG

C207 (A/T) - BLACK (BODY SIDE)

CAV

CIRCUIT

1

18RD/DG

1

20RD/DG

2

20DG/WT

3

22WT

4

22DG

C207 (A/T) - BLACK (ENGINE COMPARTMENT

SIDE)

CAV

CIRCUIT

1

18RD/DG

2

20DG/WT

3

22WT

4

22DG

8W - 80 - 16

8W-80 CONNECTOR PIN-OUTS

ZH
