REMOVAL - TAIL/STOP LAMP 1. Disconnect the negative battery cable. 2. Remove the access panel from the cargo area inte- rior trim panel. 3. Rotate the tail/stop lamp socket (2) counterclock- wise and pull it from the tail lamp unit (1). 4. Remove the bulb from tail/stop lamp socket (2). REMOVAL - TURN SIGNAL LAMP 1. Disconnect the negative battery cable. 2. Remove the access panel from the cargo area inte- rior trim panel. 3. Rotate the turn signal lamp socket (2) counter- clockwise and pull it from the tail lamp unit (1). 4. Remove the bulb from turn signal lamp socket (2). ZH LAMPS/LIGHTING - EXTERIOR - SERVICE INFORMATION 8L - 121 |
