11. Lower vehicle. 12. Verify that the shifter is in the PARK position. 13. Tighten the adjustment screw (5) to 7 N·m (65 in.lbs.). 14. Verify correct shifter operation. 15. If necessary, install the shield, covering the gear- shift and park lock cables, to the floorpan and 16. Install the floor console (Refer to 23 - BODY/IN- TERIOR/FLOOR CONSOLE - INSTALLATION), PANEL/INSTRUMENT PANEL CENTER BEZEL - INSTALLATION) and ADJUSTMENTS - GEARSHIFT CABLE Check adjustment by starting the engine in PARK and NEUTRAL. Adjustment is CORRECT if the engine starts only 1. Shift transmission into PARK. 2. Remove floor console as necessary for access to the shift cable adjustment. (Refer to 23 - BODY/IN- 3. Loosen the shift cable adjustment screw (5). 4. Raise vehicle. 5. Unsnap cable eyelet from transmission shift lever. 6. Verify transmission shift lever is in PARK detent by moving lever fully rearward. Last rearward detent is PARK position. 7. Verify positive engagement of transmission park lock by attempting to rotate propeller shaft. Shaft will not rotate when park lock is engaged. 8. Snap cable eyelet onto transmission shift lever. 21 - 390 AUTOMATIC TRANSMISSION NAG1 - SERVICE INFORMATION LX |
