1. Remove cylinder head covers. (Refer to 9 - ENGINE/CYLINDER HEAD/CYLINDER HEAD COVER(S) - REMOVAL) 2. Rotate engine until number one cylinder is at TDC on the EXHAUST stroke. 3. View the intake camshaft sprocket timing mark. The mark should be 90° from the cylinder head cover sealing surface on both right and left cylinder banks. 4. Count chain pins from the mark on the intake camshaft towards the exhaust camshaft (1)&(3). Engine is timed correctly when there are 12 chain pins between the timing marks (2) on the intake camshaft and exhaust cam- 5. If marks are not correctly aligned, proceed to Timing Chain and Sprockets for service procedures (Refer to 9 - ENGINE/VALVE TIMING/TIMING BELT/CHAIN AND SPROCKETS - REMOVAL). 9 - 2076 ENGINE - 2.7L DOHC - SERVICE INFORMATION LX |
