Fig. 27: View Of Fuel Hoses At Fuel Filter
Courtesy of GENERAL MOTORS CORP.
1. Remove the fuel hoses.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 28: View Of Fuel Filter Assembly Connectors
Courtesy of GENERAL MOTORS CORP.
2. Disconnect the fuel filter assembly connectors.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 29: Identifying Fuel Filter Bracket Bolts
Courtesy of GENERAL MOTORS CORP.
3. Remove the fuel filter bracket bolts.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 30: Identifying Fuel Filter Assembly
Courtesy of GENERAL MOTORS CORP.
4. Remove the fuel filter assembly.
DRIVE BELT TENSIONER AND GENERATOR MOUNTING BRACKET REMOVAL
