Fig. 31: View Of Electrical Harness Clip Bolts
Courtesy of GENERAL MOTORS CORP.
1. Remove the electrical harness clip bolts.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 32: View Of Drive Belt Tensioner
Courtesy of GENERAL MOTORS CORP.
2. Remove the drive belt tensioner bolt.
3. Remove the drive belt tensioner.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 33: View Of Generator Mounting Bracket
Courtesy of GENERAL MOTORS CORP.
4. Remove the drive belt tensioner and generator mounting bracket bolts.
5. Remove the drive belt tensioner and generator mounting bracket.
ENGINE COOLANT THERMOSTAT HOUSING REMOVAL
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 34: View Of Main Engine Electrical Harness Connector Bolts
Courtesy of GENERAL MOTORS CORP.
1. Remove the main engine electrical harness connector hold down bolts.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
