COOLING FAN PULLEY REMOVAL
Fig. 23: View Of Camshaft Position Sensor Electrical Connector
Courtesy of GENERAL MOTORS CORP.
1. Disconnect the camshaft position sensor connector.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 24: View Of Cooling Fan Pulley
Courtesy of GENERAL MOTORS CORP.
2. Remove the cooling fan pulley bolts and nuts.
3. Remove the cooling fan pulley.
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 25: View Of Camshaft Position Sensor
Courtesy of GENERAL MOTORS CORP.
4. Remove the camshaft position sensor retaining bolt.
5. Remove the camshaft position sensor.
POWER STEERING PUMP MOUNTING BRACKET REMOVAL
2008 Chevrolet Silverado 1500
2008 ENGINE Engine Mechanical - 6.6L - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra & Silverado
Fig. 26: View Of A/C Compressor & Power Steering Pump Bracket
Courtesy of GENERAL MOTORS CORP.
1. Remove the power steering pump mounting bracket bolts.
2. Remove the power steering pump mounting bracket.
FUEL FILTER ASSEMBLY REMOVAL
