Tighten: Tighten the oil filter to 30 N.m (22 lb ft).
4. Refill the engine oil. Refer to Approximate Fluid Capacities and/or Fluid and
Lubricant Recommendations .
OIL PAN REPLACEMENT
Removal Procedure
1. Remove the front differential. Refer to Differential Carrier Assembly Replacement .
2. Remove the starter motor. Refer to Starter Motor Replacement .
Fig. 179: View Of Crossbar Bolts & Bar (2WD)
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
Courtesy of GENERAL MOTORS CORP.
3. Remove the crossbar bolts.
4. Remove the crossbar.
Fig. 180: View Of Left Closeout Cover & Bolt
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
Courtesy of GENERAL MOTORS CORP.
5. Remove the transmission cover bolt and cover.
6. Drain the engine oil and remove the engine oil filter.
7. Re-install the drain plug and oil filter until snug.
Fig. 181: Identifying Stud & Bolt Securing Transmission To Engine (Right Side)
Courtesy of GENERAL MOTORS CORP.
8. Remove the transmission bolt and stud on the right side.
