Fig. 183: Identifying Electrical Connector (Right Side Of Engine)
Courtesy of GENERAL MOTORS CORP.
10. Disconnect the oil level sensor electrical connector (6).
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
Fig. 184: View Of Positive Battery Cable, Channel & Bolt
Courtesy of GENERAL MOTORS CORP.
11. Remove the battery cable channel bolt.
12. Slide the channel pin out of the oil pan tab.
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
Fig. 185: View Of Positive Battery Cable Fasteners
Courtesy of GENERAL MOTORS CORP.
13. Remove the following from the positive battery cable clip:
Engine wiring harness clip
Positive battery cable clip
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
Fig. 186: View Of Positive Battery Cable Clip & Bolt
Courtesy of GENERAL MOTORS CORP.
14. Remove the engine oil cooler lines from the positive battery cable clip.
15. Remove the positive battery cable clip bolt and clip.
2008 Hummer H2
2008 ENGINE Engine Mechanical - 6.2L - H2
