Chevrolet Silverado / GMC Sierra. Manual - part 2654
Fig. 228: Extension
Courtesy of GENERAL MOTORS CORP.
19. Install the extension, as shown.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 229: Using 10 Mm Socket On 12 Bolts At Transmission Rear Case
Courtesy of GENERAL MOTORS CORP.
20. Using a 10 mm wrench, install the 12 screws that secure the casing.
21. Tighten the screws.
Tighten: Tighten the screws to 24-37 N.m (18-28 lb ft).
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 230: Park/Neutral Position And Backup Lamp Switch
Courtesy of GENERAL MOTORS CORP.
22. If removed, install the reverse lamp switch.
23. Tighten the reverse lamp switch.
Tighten: Tighten the reverse lamp switch to 16-21 N.m (12-16 lb ft).
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
