Chevrolet Silverado / GMC Sierra. Manual - part 2655
Fig. 232: Using 10mm Wrench On Vehicle Speed Sensor Bolt
Courtesy of GENERAL MOTORS CORP.
25. Using a 10 mm wrench, tighten the vehicle speed sensor bolt.
Tighten: Tighten the vehicle speed sensor bolt to 16-21 N.m (12-16 lb ft).
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 233: Shift Tower
Courtesy of GENERAL MOTORS CORP.
26. Install the shift tower.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 234: Using 10mm Wrench On Shift Tower Screws
Courtesy of GENERAL MOTORS CORP.
27. Using a 10 mm wrench, tighten the 4 shift tower screws.
Tighten: Tighten the screws to 10-17 N.m (8-13 lb ft).
DESCRIPTION AND OPERATION
MANUAL TRANSMISSION DESCRIPTION AND OPERATION
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 235: Transmission Identification Plate
Courtesy of GENERAL MOTORS CORP.
The TR-3450 series transmissions have an advanced design with 5 forward gears and 1 reverse
gear that offers a greater efficient torque-weight capacity than any other 5 speed transmission in
its class.
SPECIAL TOOLS AND EQUIPMENT
SPECIAL TOOLS
Callout
Component Name
1
Transmission Model
2
Transmission Number
3
Assembly Date
4
Series Number
IMPORTANT: All TR-3450 transmissions are identified by a model number and
a series number, as well as a manufacture date. This information
is stamped on the transmission identification plate and fastened
on the case.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
