Chevrolet Silverado / GMC Sierra. Manual - part 2653
Fig. 224: Speedometer Drag Ball
Courtesy of GENERAL MOTORS CORP.
15. Install the speedometer drag ball.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 225: Installing Speedometer Gear
Courtesy of GENERAL MOTORS CORP.
16. Using a driving tool, install the speedometer gear.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 226: Speedometer Gear Retainer
Courtesy of GENERAL MOTORS CORP.
17. Using retainer pliers, install the retainer that secures the speedometer gear.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
