Chevrolet Silverado / GMC Sierra. Manual - part 2600
Fig. 19: View Of Backup Lamp Switch
Courtesy of GENERAL MOTORS CORP.
1. Install the backup lamp switch.
Tighten: Tighten the switch to 37 N.m (27 lb ft).
NOTE:
Refer to Component Fastener Tightening Notice .
IMPORTANT: The backup lamp switch has pre-applied thread sealant on
the threads.
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 20: Locating HO2S Electrical Connector At Harness (Manual 2WD)
Courtesy of GENERAL MOTORS CORP.
2. Connect the backup lamp switch electrical connector (3).
3. Lower the vehicle.
VEHICLE SPEED SENSOR REPLACEMENT
Removal Procedure
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
Fig. 21: Locating HO2S Electrical Connector At Harness (Manual 2WD)
Courtesy of GENERAL MOTORS CORP.
1. Raise and suitably support the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Disconnect the vehicle speed sensor (VSS) electrical connector (1).
2008 Chevrolet Silverado 1500
2008 TRANSMISSION Manual Transmission - Tremec 5-Speed (TZ0)
